| Products |
|
|
| |
Item |
|
|
Category |
|
|
Specification |
|
| |
General |
|
Channel |
|
1 Channel |
|
| |
|
Camera |
|
1/3.2" CMOS Image Sensor / 2Mega Pixels |
|
| |
|
LCD |
|
2.8 inch Wide-angle Full Touch LCD(320x240) |
|
| |
|
Lens |
|
6 Glass, True HD |
|
| |
|
Resolution |
|
Up to 1280x720p |
|
| |
|
Frame |
|
30 fps |
|
|
|
|
|
|
|
|
| |
Size & Weight |
|
Size |
|
78.5 x 55.1 x 16.8mm |
|
| |
|
Weight |
|
82g (with product holder : 111g) |
|
|
|
|
|
|
|
|
| |
Compression |
|
Video |
|
H.264 / Mpeg-4 AVC |
|
|
|
|
|
|
|
|
| |
Angle |
|
|
|
Up to 120 degree in diagnoal |
|
|
|
|
|
|
|
|
| |
Memory |
|
Composite |
|
Up to 32GB SD Card compatible |
|
|
|
|
|
|
|
|
| |
Recording Mode |
|
|
|
Driving Recording, Parking Recording, Event(Impact) Recording |
|
|
|
|
|
|
|
|
| |
Recording Type |
|
|
|
Nomal, Event, Motion |
|
|
|
|
|
|
|
|
| |
Sound Recording |
|
|
|
Microphone |
|
|
|
|
|
|
|
|
| |
Software |
|
PC Viewer |
|
PC Manager(Windows PC) |
|
|
|
|
|
|
|
|
| |
Battery Voltage Control |
|
|
|
Built-in circuit to detect voltage(Supported Auto Shutdown Voltage Setting, Auto Shutdown Timer, and running Auto ParkingRecording |
|
|
|
|
|
|
|
|
| |
GPS |
|
|
|
Supported(Optional) |
|
|
|
|
|
|
|
|
| |
Operation Temperature |
|
|
|
-20℃ ~ +60℃ |
|
|
|
|
|
|
|
|
| |
Rated Voltage |
|
|
|
DV 12V ~ 24V |
|
|
|
|
|
|
|
|
| |
ETC |
|
|
|
G-Sensor, Speaker, LED Status Indicator External GPS Module |
|
 |
|
|
